Comparison of PD064VT5 and PD064VL1
From: The Site Author: admin DateTime: 08/01/2016
|
Comparison of PD064VT5 and PD064VL1 |
|
|
These two Taiwan PVI LCD panels are widely used in industrial application, they are different mass production time according the market's change. In the earlier embedded boards, the boards were almost with TTL interfaces,with the development of chipset technologies, many LCD controller board manufacturers make the boards with only LVDS interface, then the converter board from TTL to LVDS are used popularly for a moment. As the demand of the TFT in the market, many LCD panel manufacturers also started to make LVDS interface TFT color panels, PVI also released LVDS LCD Panel（PD064VL1）, and well received in the industrial application market. The comparision of PD064VT5 andPD064VL1 is as below:
Model: PD064VT5 PD064VL1
Resolution 640*R.G.B*480 dots 640*R.G.B*480 dots Dot Pitch 0.0675*0.203 mm 0.2025*0.203 mm Active Area 129.6*97.40 mm 129.6 x 97.4 mm Viewing Angle L/R/U/D:50/50/15/35 deg L/R U/D:60/60 40/55 deg Signal Category TTL LVDS Brightness 400 Cd/m2 400 Cd/m2 Power Consumption 4.8 W 4.8 W Outline Dimension 175.4*126.9*12.5 mm 175 .4 x 126 .9 x 12.5 mm Net Weight 340土10 G 340土10 G Working Temperature -20~+70℃ -20 ~ +70 Storage Temperature -30~+80℃ -30~+80℃
From this comparision, we can know that, these 2 LCD panels PD064VT5 and PD064VL1, not only the signal interface are different from TTL to LVDS, the viewing angle also have big breakthrough, it is more compatiable for using industrial application.
|
http://www.panelook.com/PD064VT5_E%20Ink_6.4_LCM_parameter_6889.html
http://www.panelook.com/PD064VL1_E%20Ink_6.4_LCM_parameter_6884.html
